TECHNICAL SPECIFICATIONS
Product Code | LBR-OS
|
|---|---|
Footprint (L x W x H) | 77.5” x 66” x 75.5” (metric cm: 197 x 168 x 192)
|
Recommended Live Area (L x W x H) | 120” x 120” x 75.5” (metric cm: 305 x 305 x 192)
|
Machine Weight | 400 lbs (182 kg)
|
Max Training Weight | 800 lbs (363 kg)
|
Vertical height from floor to Top Bar Support | 63” (160 cm)
|
Vertical height from floor to Bottom Bar Support | 37” (94 cm)
|
Vertical height from Top Bar Support to Bottom Bar Support | 26″ (66 cm)
|
Vertical height between Bar Supports | 6.5″ (16.5 cm)
|
Vertical height from floor to Bar Catch | 28.5″ (72.4 cm)
|
Weight Horns | 8
|
Weight Horn Capacity | 4 x 45 lb (20 kg) plates per horn
|
Warranty | 10 year limited warranty on structural frame (coatings excluded), 5 year on pulleys, weight plates & guide rods, 1 year on bearings, cables, grips & electrical, 90 days on upholstery, springs & any items not specified
|
