LIFE FITNESS

INTEGRITY SERIES LIFECYCLE UPRIGHT EXERCISE BIKE

Multiple upright bike combinations offer comfortable and inviting experiences for any exerciser. The Integrity Series benefits from a sleek and modern design, and is rooted in more than 20 years of reliability and innovation. Each bike offers wireless internet connection, which provides valuable asset management data and insights about your exercisers.
Wireless internet connection allows facilities to monitor valuable asset data and make easy software updates. Console choices and four color options let you create the cardio experience that best fits your exercisers.

TECHNICAL SPECIFICATIONS


Description	Integrity D: Deluxe; Integrity S: Simple
Console	Integrity D and S: SL, ST, SE3 HD
Handlebars	Integrity D: Deluxe Racing Handlebars, egonomic design w/elbow support; Integrity S: Racing Handlebars
Remote Buttons	Integrity D: Yes; Integrity S: No
Saddle	Integrity D and S: Improved Confort Curve™ Seat
Pedals	Integrity D: Self-Leveling Wide Ride™ Pedals; Integrity S: Wide Ride™ Pedals
Pedal size	Integrity D and S: 6.56″ x 5.5″ (16.7 cm x 14 cm)
Pedal Straps	Integrity D and S: Yes
Accessories Holder	Integrity D and S: Integrated Accessory Tray
Color	Integrity D: Arctic Silver, Titanium Storm, Black Onyx, Diamond White; Integrity S: Arctic Silver, Black Onyx
Seat Adjustment	Integrity D and S: 42 Fine-Tuned Seat Adjustments w/easy to reach height adjustment lever; Lowest: 18.25″” Highest: 31.5″” Delta: 13.25″” Adjustment 14″
Step-over height	Integrity D and S: 21.14″ (536.9mm)
User Height Range	Integrity D and S: 4’9″ – 6’5″
Max User Weight	Integrity D and S: 400 lb (182 kg)
Transport Wheels	Integrity D and S: Yes
Drive System	Integrity D and S: Generator Drive System with 8-Ribbed Poly-V Belt resistance system
Resistance Levels	Integrity D and S: 26*
Resistance Type	Integrity D and S: Hybrid Eddy current brake with brushless internal generator for low drag and high power capability
Belt Drive	Integrity D and S: Single stage drive with self-tensioning idlers for minimal mechanical drag and low maintenance
Multi Ribbed Belt Drive	Integrity D and S: Yes
Generator	Integrity D and S: Generator
Crank size	Integrity D and S: 165mm (6.5″)
Touch	Integrity D and S: Yes
Telemetry	Integrity D and S: Yes
Self-powered	Integrity D and S: All non Discover consoles
Power Requirements	Integrity D and S: North America: 120V, 20A outlet with dedicated line, neutral, ground wires and dedicated circuit breaker, Japan: 100V, 20A; International: 230V, 10A outlet with dedicated line, neutral, ground wires and dedicated circuit breaker, Japan: 200V, 10A; Discover Consoles – 24V, 3.75A (90W) Attachable TV- 24V, 2.5A (60W) SL Non-Treads, Optional Power – 24V, 2.5A (60W)
Minimum Watts	Integrity D and S: 29 Watts
Maximum Watts	Integrity D and S: 900 Watts
Minimum RPM	Integrity D and S: 29 Watts
Assembled Dimensions	Integrity D and S: Length 41.5″ (105cm), Width 24.5″ (62cm), Height 54.5″ (138cm)
Assembled Weight	Integrity D and S: 169lbs (76.5kg)
Shipping Weight	Integrity D and S: 200lbs (91kg)
Shipping Configurations (for non-installed purchases)	Integrity D and S: 63″ x 27″ x 39″ (160.02 cm x 68.58 cm x 99.06 cm)
Warranty	1 year
